input
Voltage 85~125 V or 170~250V can be selected by jumper
Frequency 50~60Hz(universal)
Phase number 1
Number of lines 2
exportation
Voltage When the input voltage AC is 207V, the maximum output DC is 90V
The current continuous output is 4A, allowing 6A instant current for 10 seconds
The minimum excitation resistance is 15Ω
Steady-state voltage regulation rate ±1.0%(within the range of 4% engine speed)
External voltage adjustment External resistance 1KΩ/1W, adjustable range >±5%
Excitation voltage AVR input is 3.5V AC
Low frequency protection
Set protection point 93% rated frequency
At a slope of 30Hz it is 170%
Thermal drift The AVR ambient temperature changes by 40℃, and the drift value is 1%
environment
Vibration 20-100Hz 50mm/s 100Hz-2kHz 3.3g
Relative humidity 0-60℃ 95%
Operating temperature -40℃~+70℃
Storage temperature -55 ° C to +80 ° C
Product specification
Overall dimensions Width 104X Height 139X Depth 39(mm)
Installation dimensions Width 80X height 115(mm)xΦ5-4
Weight 300g
