SENSING INPUT: 1.Voltage :190-264V ac max, 2 or 3 phase 2.Frequency :50-60 Hz nominal POWER INPUT (PMG): 1.Voltage :170-220V ac max, 3 phase, 3 wire 2.Current :3A/phase 3.Frequency :100-120 Hz nominal OUTPUT: 1.Voltage max 120V dc 2.Current continuous 3.7 A (see note 1) Intermittent 6A for 10 secs. 3.Resistance 15 ohms minimum REGULATION: +/- 0.5% RMS with 4% engine governing (see note 2) THERMAL DRIFT: 0.02% per deg. C change in AVR ambient (note 3) SOFT START RAMP TIME: 0.4 - 4 seconds TYPICAL SYSTEM RESPONSE: 1.AVR response 10 ms 2.Filed current to 90% 80 ms 3.Machine Volts to 97% 300 ms EXTERNAL VOLTAGE ADJUSTMENT: +/-10% with 5 k ohm 1 watt trimmer
