LIXISE ATS700 Automatic Transfer Switch Controller for Generator Mains Power System

LIXISE ATS700 Automatic Transfer Switch Controller for Generator Mains Power System

$102.60 USD
$102.60 USD
Sale Sold out
Shipping calculated at checkout.
project description
Operating voltage 1. DC 8.0V~35.0V, continuous power supply.

2. AC (90–280) V during AC power supply L1N1/L2N2

 (ATS700B/ATS700BI/ATS700S)
Power Consumption <5W (standby mode:  ≤2W)
ACvoltage input AC systen ATS700/ATS700I ATS700B/ATS700BI/ATS700S
3P4W(L-L) (80-625)V (80-480)V
3P3W(L-L) (80-625)V (80-625)V
1P2W(L-L) (50-360)V (50-280)V
2P3W(L-L) (A-B) (80-625)V (80-480)V
Rated Frequency 50/60Hz
Close Relay Output 16A AC250V passive output
Auxiliary Relay
Output 		16A/7A AC250V Volts free output
Digital Input Port GND (B-) effective
Communication RS485 isolated interface, MODBUS protocol
Outline dimension 197mmx152mmx47mm
Open hole size 186mmx141mm
Work Conditions Temperature: (-25~+70)  °C      Relative humidity: (20~93)%RH
Storage Temperature Temperature: (-25~+70)  °C
Protection Leve  IP55: when water proof gasket ring inserted between panel and housing.
 Insulation strength Apply an AC 2.2 kV voltage between the high-voltage and low-voltage
 terminals; the leakage current shall not exceed 3 mA within 1 minute.
weight ATS700/ATS700I: 0.7kg
ATS700B/ATS700BI/ATS700S: 0.8kg
