Working voltage: Continuous power supply from 8V to 36V Overall power consumption: Standby: 24V: MAX 1W Work: 24V: MAX 2W Alternating current voltage in put:Single phase two wire 30VAC-450VAC (ph-N) Engine speed signal range: 50-9000Hz Maximum cumulative running time:999.99 hours (minimum storage time 6 minutes) Fuel output: 1Amp DC +VE power supply voltage output Motor output: 1Amp DC +VE power supply voltage output Configurable relay 1: 1Amp DC +VE power supply voltage output Configurable relay 2: 1Amp DC +VE power supply voltage output Configurable relay 3: 1Amp DC +VE power supply voltage output On-off input: The battery negative terminal is effective Going: -25-65℃ Storage conditions: -40-85℃ Levels of protection:IP65: When a waterproof ring is added between the controller and the control screen. Insulation grade:When AC2.2kV voltage is applied between the high-voltage ter minal and the low-voltage terminal, the leakage current is not greater than 3mA within 1min. Outline dimension 106mm*86mm*45mm Opening size 78mm*66mm Weight 0.25KG
