LIXiSE LXC6320 LCD Screen Genset Controller | 32-bit ARM Chip, MODBUS Three-Remote, SMS Alarm, Multi-Industry Use

LIXiSE LXC6320 LCD Screen Genset Controller | 32-bit ARM Chip, MODBUS Three-Remote, SMS Alarm, Multi-Industry Use

$92.40 USD
$92.40 USD
促销 售罄
结账时计算的运费。

LIXiSE LXC6320 Series Genset Controller Product Introduction

The LXC6320 series intelligent genset controller adopts a 32-bit microprocessor real-time operating system. It supports precise measurement of 16 types of parameters, configuration of 32 input channels, 35 early warning protection parameters and 85 output control parameters, with 98% of all adjustable parameters configurable directly on the front panel. Equipped with a graphic LCD display, it visualizes complete engine and electrical operational data. Widely applied to small power stations, biogas power plants, oilfield power equipment, field engineering machinery, industrial factories, fire water pumps, mobile base stations and other scenarios. Compatible with gasoline, diesel, natural gas and biogas generator units, it has been mass-matched by numerous well-known domestic and overseas manufacturers.

Core Hardware Advantages

  1. High-integration 32-bit ARM microcontroller greatly improves overall equipment stability and reliability.
  2. 128×64 backlit dot-matrix LCD screen, multi-language interface including Chinese & English for easy on-site commissioning.
  3. Wide DC power supply range of 8~35VDC, compatible with all standard starting battery voltages.
  4. All relay-type output ports for reliable switching control.

Complete Control & Protection Functions

  1. Auto Start/Stop & ATS Transfer: Fully automatic startup/shutdown for diesel/gas gensets, automatic mains-generator ATS switchover, comprehensive fault alarm and shutdown protection.
  2. Multi-mode Startup Validation: Selectable startup success detection via speed sensor, oil pressure, generator frequency or alternator charging signal, adapting to diverse working conditions.
  3. Parameter Storage: All settings editable via PC through USB, RS232 or optional RS485 ports, permanently saved in internal FLASH memory without data loss after power cut-off.
  4. MODBUS Three-Remote Function: Realize remote measurement, remote signaling and remote control via standard MODBUS protocol (RS485 interface optional).
  5. SMS Alarm & IoT Remote Monitoring
    • Automatic SMS alert notifications sent to up to 5 preset mobile numbers once faults occur; users can remotely control gensets and check operational status via SMS commands.
    • Advanced IoT cloud monitoring via GPRS cellular network (requires optional LXI680 GPRS module), supporting real-time remote access anywhere with internet coverage.
  6. 200 Historical Fault Records: Automatically store critical snapshot data including oil pressure, coolant temperature, voltage and current at the exact moment of each failure for troubleshooting.
  7. RTC Timed Operation: Built-in real-time clock supports daily/weekly/monthly auto startup with configurable load output for regular automatic equipment maintenance.
  8. Rich Analog Sensor Inputs: 5 fixed analog channels (2 temperature, 2 oil pressure, liquid level) + 2 programmable analog channels configurable for temperature, pressure or liquid level signals. Multiple pre-set sensor curves are available with fully customizable curve parameters.
  9. Multi-scene Operation Modes: Supports generator/water pump control; standalone meter mode (display & alarm only, no relay action) is also optional.

Specialized Industry Solutions

1. Generator Rental Industry

Perfect management solution for rental fleets:
  • Remote full-data monitoring of oil pressure, coolant temperature, voltage, current, power and all running parameters via PC.
  • Remote parameter modification to prevent improper operation and unit damage.
  • 200 detailed fault logs with timestamp, failure cause and real-time snapshot data uploadable to central monitoring terminals.
  • Multi-level password authority management for standardized rental asset control.

2. Fire Water Pump Industry

Disable electrical parameter measurement function, then utilize programmable I/O ports and internal custom logic to build fully automatic pump control systems. It replaces the traditional combination of PLC + simple diesel controller for more stable and reliable overall operation.

3. Air Compressor Industry

Turn off voltage measurement & protection functions, configure custom analog input channels, activate overload protection, and match programmable digital inputs to realize automatic startup, temperature & pressure regulation and customized protection thresholds.
